SEC-H800-100T PEM hydrogen fuel cell stack assembly machine
Compact size, effective, cost-wise system
The design of this semi-automatic stacker is to develop a semi-automatic stacking equipment for large-scale PEM hydrogen fuel cell batteries stacking and packaging needs. The stacking of other materials is done manually. The high-precision servo hydraulic pressing system ensures the precise pressure of each stack; manually locks the studs, and uses the differential pressure method to perform multi-directional air tightness tests on the stack.
This is automated industrial adhesive material dispensing robot works with Scara turntable dispensing machine SEC-NR550-UR
Pressure Plate Pump for High-Viscosity Fluids
Functional features:
Suitable for pumping high-filler and high-viscosity glue
● Provide high output pressure
With pneumatic motor, pressure output ratio is 43:1;
(Example: According to the factory standard air pressure of 0.6Mpa, it can provide 25.8Mpa glue supply pressure)
● Provide large displacement: one circulation pump can deliver 170CC of fluid
● Has excellent wear resistance
a. The plunger rod is made of specially treated carbon steel or ceramic material;
b. The key structure that withstands impact and abrasion is nested with tungsten steel;
● Unique sealing structure design and the use of special sealing materials;
The above characteristics can greatly extend the life of the seal
● Easy installation and maintenance
The plunger rod and seal are easy to replace; Optional maintenance kit;
Performance:
Precision Dual Y Platform
Simple and practical, easy to program, realize automatic dispensing operation at the most economical price
Economical double Y platform:
■ With higher flexibility
■ Alternate operation to improve production efficiency
■ Powerful application expansion module, more extensive application
■ Expandable double Y double rotation to achieve six-axis alternate dispensing function
Second Double liquid static glue dispensing valve
F-J series two-liquid static glue dispensing valve is a two-component back-suction static mixing switch valve, which acts on the switch and mixing of two-component glue in the flow channel. It uses a back-suction switch to control the two glues A and B to enter the mixing tube, and then apply them to the product after static mixing! It is suitable for a variety of two-component mixing and coating processes,2 component adhesive dispenser valve.
Features
● It acts on the switch and mixing of two-component fluids in the flow channel, using pull-back switch and static mixing.
● It controls the A and B liquids to enter the static mixing tube for mixing at the same time.
● It is suitable for medium and low viscosity fluids.
● It can be connected to various types of static or dynamic mixing tubes and is suitable for various forms of dual-liquid dispensing equipment.
SEC-200S High precision micro-computer dispenser controller:
SEC-200S, Digital display high precision adhesive dispenser machine，Using the latest single-chip technology，with professional production in China。And is Widely used in electronics, aerospace, optics, automotive,watches, medical, petroleum, packaging, jewelry and machinery etc.
SEC-200S, the main feature of Digital display high precision dispensing machine is ：It is easy to apply a precise amount of liquid that is precisely adjusted. Bring high quality products, improve production efficiency, and ensure excellent quality and quantity in the production process.
